KDZ-130 Automatic Cartoning Machine
Summary: Horizontal box filling machine has wide application range, high production efficiency, and can be used for multiple purposes.
- Department
- International Trade Department
- Phone
- +86-577-63032858 · +86-577-63032878 · +86-577-63032198
- yanfeng@yanfeng.cn
Summary:
Horizontal box filling machine has wide application range, high production efficiency, and can be used for multiple purposes. At the same time, the machine can be used with aluminum-plastic, aluminum-aluminum and other packaging machines, and can meet the requirements of the national drug production quality management standard “GMP”.
This machine can be a variety of different specifications of different products, plate, ointment, bottles, bags and other items in the box, while suitable for food packaging, cosmetics packaging and related industries packaging.
According to the different requirements of users, the product can be replaced regularly, and the mold adjustment time is short, the assembly and debugging are simple, suitable for the production of a single variety of large quantities, and can meet the production of small batches and varieties of users.
Optional according to customer requirements, manual folding machine, hot melt glue machine, date coding machine, camera detection, weighing detection and so on. This machine can be connected to front-end product production equipment, back-end packaging equipment, to achieve a high degree of automation of the whole line, improve production capacity, reduce production costs and labor costs.
| 型号Model: | KDZ-130 | |
| 速度Speed： | 30-60boxes/min | |
| 纸盒尺寸 Box size(L*W*H)： | （70-250)*(25-100)*(12-90)mm | |
| 说明书（选配） Instruction paper（optional）： | Paper material | 50-70g/m2 |
| Unfolded size range | （80-300）mm*(70-210)mm | |
| Folded size range | 1-4 folded(70-210)mm X(20-40)mm | |
| 纸盒材料 Box paper material： | 250~450g/㎡ | |
| 主电机功率 Main motor power： | 1.5 kw | |
| 电源Power supply： | 380V 50Hz(220V 60 Hz) | |
| 工作压力Work pressure： | 0.5Mpa,0.6m³/h | |
| 气源 Compressed gas consumption: | ≥0.9m³3/h | |
| 机器尺寸Dimensions(length×width×height): | 3700(L)×1500(W)×1900mm(H) | |
| 机器重量Machine weight： | 1800KG | |
| 接受定制 Special Size Customization |
